Electrified concertina coils combine razor wire barriers with high-voltage electric deterrent systems. GABION-S™ provides advanced electric razor wire for prisons, military bases, borders, and critical infrastructure.
What are Electrified Concertina Coils?
Electrified Concertina Coils (also known as electrified razor wire or electric concertina coil fencing) integrate traditional concertina razor wire with a high-voltage electric deterrent system.
This dual-layer protection—cutting barrier + electric shock deterrent—is widely used in high-risk security environments such as prisons, military bases, border fences, and critical infrastructure.
GABION-S™ manufactures electrified coils using superior galvanized, heavy-zinc, stainless steel, and Galfan-coated materials for long-term outdoor durability.
How Electrified Concertina Coils Work?
Stainless steel or galvanized steel strips with sharp blades prevent climbing and cutting.
Non-lethal but strong electric shocks deter intruders from touching or tampering.
Works with chain link fences, palisade fences, wall-tops, security posts, etc.
Any interference triggers sensors and sends signals to control centers.
Material Options
Razor Wire Material
- Galvanized steel core wire
Zinc: 60–80 g/sqm - High-zinc steel core wire
Zinc: 200–260 g/sqm - Stainless steel core wire
Grades: 430 / 201 / 304 / 316 - Galfan Wire (Zn–5%Al / Zn–10%Al)
Zinc: ≥200 g/sqm
Steel Strip Options
- Hot-dipped galvanized strip
- Heavy zinc coated strip
- Stainless steel strip (430 / 201 / 304 / 316)
Technical Specifications
| Item | Specification |
|---|---|
| Coil Type | Concertina / Cross Type / Single Coil |
| Outside Diameter | 450 mm, 500 mm, 600 mm, 730 mm, 900 mm |
| Blade Type | CBT-60 / CBT-65 / BTO-22 / BTO-28 / BTO-30 |
| Core Wire Diameter | 2.5–3.2 mm |
| Material | Galvanized, High-Zinc, Galfan, Stainless Steel |
| Electric Voltage | 5,000 – 10,000 V (non-lethal pulses) |
| Pulse Type | High-voltage, intermittent shock |
| Power Source | Security energizer (compatible with all models) |
| Operating Temperature | -40°C to +70°C |
| Mounting | Fence-top, wall-top, stand-alone posts |
| Coating Options | HDG, Galfan, Stainless Steel, Powder coating |
Features
Dual Security System
- Sharp blades provide physical deterrence
- High-voltage pulses stop climbing attempts instantly
Long-Lasting Corrosion Resistance
- Optional heavy zinc
- Galfan alloy
- Stainless steel grades up to 316
Compatible With Existing Fencing
- Chain link fences
- Palisade fencing
- Concrete wall-tops
- Security posts & border fences
High Intrusion Detection Capability
- Integrates with alarms & monitoring
- Detects tampering or cutting attempts
Wide Installation Options
- Fixed brackets
- Wall-top Y-posts
- Spiral cross-coils
- Stand-alone electric fence systems
Applications
Electrified Concertina Coils are widely used in:
- Prisons & detention centers
- Military bases
- Border & frontier security
- Airports & naval facilities
- Government buildings
- Industrial manufacturing plants
- Oil & gas stations
- Power substations
- High-value storage facilities
- Homeland security infrastructure
Why Choose GABION-S™
- Professional manufacturer of razor wire & security fencing
- High-zinc, Galfan, stainless steel materials available
- Exported to Middle East, Europe, Africa, Southeast Asia
- Custom voltage & coil diameter options
- Full QC system for government & military contracts
- OEM & engineering solutions available
